The smart choice for thermal modified wood chamber
Prossional Maker
20 years focus on thermal modified wood solutions;
Custom made as per customer’s requirements.
Techinical Strength
Many patents of thermal modified wood chamber;
Free modification modification settings as per your wood & applications.
Competitive Prices
High quality, stable performance, competitive prices compared with overseas makers;
We can send engineer overseas for field installation & training.
Thermally modified wood is wood that has been modified by a controlled pyrolysis process of wood being heated (> 180 °C) in absence of oxygen inducing some chemical changes to the chemical structures of cell wall components (lignin, cellulose and hemicellulose) in the wood in order to increase its durability.
Industrial thermal modification processes typically aim at improving the biological durability of less durable wood species and enhancing the dimensional stability of the wood or wood-based products.
Our thermal modified wood chamber can use electric heating for thermal oil boiler heating as heat source, PLC automatic control, HMI screen easy to operate.
Features
Inner wall material: 304stainless steel plates
Kiln body outer plate: aluminium alloy orange peel embossed corrugated board
Kiln body skeleton: Carbon steel square pipe and I-beam steel structure
Single open kiln door: aluminium alloy structure
Control mode: touch screen automatic
Control style: No needing special person look after, only occasionally inspection
Circle style: top winding type, forced convective cycle
Heating mode: electrical heating or thermal oil boiler
Conditioning humidity: physical automatically is main, electric steam is assistant
Cooling mode: forced cooling
Steam treatment: by dynamic condensation
Loading mode: electric all stainless steel rail car
Equipment platform: I-beams steel structure
Advantages
Always focused on heat treatment equipment
Powerful functions: high temperatue finalization, in depth carbonization, secondary drying, health balance
Color depth: adjustable, in uniform
Conditioning: physical & electric
Custom made to satisfy customers’ requirements
Strong aftersales market support
Improve quality: not easy to crack, bend
Physical exchange: completely degrease, desugar, dilute tree sap
Effective capacity: 10-100cbm (actual piling)
Loading: electric rail cart
Rigorous, mature heat process
Physical treatment: no chemicals
Environmental design: close cycle treatment, 0 waste air water emission
Kiln temperature: ≤240℃
Control: automatic, no need worker around
Free heat process upgrade
Coniferous wood fresh cutting directly carbonizing no need to dry first
Tail gas treatment: adjustable, both wind & water cooled
Circulation: wind, top, side, end
Construction: plat ground
Colors of some wood species
Whole house furniture custom made 140℃ to 160℃
Solid wood furniture 150℃ to 185℃
Wood floor 165℃ to 190℃
Garden wood house 178℃ to 212℃
